Showcase

Below you can find a showcase of simulations ran in EMerge and compared against commercial solvers or measurements. Where possible, references to associated papers are provided.

E Field Animation

S-parameters

E Field Animation

1/3

Via transition

C. Li et al., "Mode-decomposition-based Equivalent Via (MEV) Model and MEV Model Application Range Analysis," 2023 APEMC/INCEMIC

Dual band rat-race coupler

S-parameters

Dual band rat-race coupler

1/2

Dual-band Rat Race Coupler

R. Sinha, "Design Guidelines and Applications for Dual-Band Rat-Race Couplers and Gysel Power Dividers With Unequal Amplitude Imbalances [Application Notes]," in IEEE Microwave Magazine, vol. 26, no. 3, pp. 88-98, March 2025, doi: 10.1109/MMM.2024.3415241.

E-field animation

S-parameters

E-field animation

1/3

Crosstalk simulation

Comparison data provided by a kind discord member!

E-field animation

S-parameters

E-field animation

1/2

Wideband Band-pass Filter

W.-C. Weng, “Design and Optimization of Compact Microstrip Wideband Bandpass Filter Using Taguchi’s Method,” IEEE Open Access Journal, vol. 10, 2022, pp. 107242-107249.
